Art. No. 85-201-00-00
independant® 201 M system
| Item number | 85-201-00-00 |
|---|---|
| Serial number guided | No |
| Nominal frequency | 60 / 50 Hz |
|---|---|
| Brake system | Electropneumatic passive brake |
| Nominal voltage | 100 - 240 VAC |
| Power | 220 W |
| IP classification | IP 20 |
| Vertical lift | ca. 690 mm / + 20 /- 30° (±2°) |
| Swiveling area: upper and intermediate bearing | 340 ° |
| Swiveling area: console tube | 340 ° |
| Nominal voltage SurroundLED | 12 VDC |
| Dimensions of ceiling covering SINGLE | Ø 600 (H = 150 or H = 50) or 700 x 700 (H = 150 or H = 50) |
| Dimensions of ceiling covering TANDEM | 700 x 700 (H = 150 or H = 50) |
| Positioning steps for the end stops of the bearings: upper bearing | 15 ° |
| Positioning steps for the end stops of the bearings: console tube | 22.5 ° |
| Payloads and dead weights of the Independant® 201 M | Single extension arm: 1,015 mm (motor arm) Payload: 250 kg Dead weight: 60 kg Dual extension arm: 600 / 1,015 mm Payload: 250 kg Dead weight: 100 kg Dual extension arm: 800 / 1,015 mm Payload: 250 kg Dead weight: 105 kg Dual extension arm: 1,000 / 1,015 mm Payload: 250 kg Dead weight: 110 kg Dual extension arm: 1,200 / 1,015 mm Payload: 250 kg Dead weight: 115 kg Dual extension arm: 1,400 / 1,015 mm Payload: 240 kg Dead weight: 120 kg Dual extension arm: 1,600 / 1,015 mm Payload: 200 kg Dead weight: 125 kg |
| Article text | independant® 201 M system |
|---|
| Brochures | |
|---|---|
| Technical accompanying documents |
